NEMA 23 Integrated Stepper Motor + Drive + Controller (Single Stack Motor)
|Dimensions||8 × 10 × 7 in|
The IMC Family is an Integrated Stepper Motor with built-in Controller and Amplifier.
Each IMC Module can be programmed independently through the ModuSystems Snap2Motion Software for easy configuration and commissioning. For multi-axis systems, the IMC’s can be daisy chained via RS-485 for a coordinated system giving the full capability of each unit individually, but from a single interface.
In stock (can be backordered)
- Integrated Stepper Motor + Controller & Driver
- 12-48Vdc Input, 4A Output
- Microstepping at 256 mSteps/Full Step
- (3) Digital Inputs (5-24V)
- (3) Digital Outputs (5-24V)
- (1) 16-bit Analog Input
- (1) 5V Dedicated Output
- Closed Loop Control of a Stepper
- Integrated Status LED
