NV23-2
NEMA 23 Servo Motor - Double Stack Length
$445.26 – $473.27
| Weight | 1.94 lbs |
|---|---|
| Dimensions | 8 × 10 × 7 in |
| Rear Shaft Option | E, AE |
Nema 23 Servo Motor – Double Stack Length
Key Features
- 2.3″ Square NEMA 23 Servo Motor
- 3 Phase Brushless DC
- Low Cogging Electro-Magnetic Design
- Low Audible & EMI Noise
- Kv = 9.8 V / kRPM
- Kt = 13.3 oz-in / A
- Continuous Rated Current = 3.0A
- Maximum Peak Current = 12.4A
- Maximum Speed = 4000 RPM
- Rotor Inertia = 0.0047 oz-in-sec2
- Motor Length = 3.0 in.
- Weight = 1.94 lbs
