NV23-3
NEMA 23 Servo Motor - Triple Stack Length
$477.66 – $505.67
| Weight | 3 lbs |
|---|---|
| Dimensions | 8 × 10 × 7 in |
| Rear Shaft Option | E, AE |
Nema 23 Servo Motor – Triple Stack Length
Key Features
- 2.3″ Square NEMA 23 Servo Motor
- 3 Phase Brushless DC
- Low Cogging Electro-Magnetic Design
- Low Audible & EMI Noise
- Kv = 11.2 V / kRPM
- Kt = 15.1 oz-in / A
- Continuous Rated Current = 3.2A
- Maximum Peak Current = 12.6A
- Maximum Speed = 4000 RPM
- Rotor Inertia = 0.0071 oz-in-sec2
- Motor Length = 4.0 in.
- Weight = 2.94 lbs
